BOBTAILS

Technoimpianti Apm bobtails are installed on all main truck brands and with several possible options. Volume capacity may vary from 3 to 40m3, depending on truck and national legislation. Also for bobtails our designed is depending on end user needs and country, with stiff and robust anchoring design for off-road and bad road conditions, aluminum baffles and light anchor system for maximized payload in Western countries. Standard scope of supply is composed by a fixed tank and a transfer and metering plant with LPG pump, volumetric meter and delivery hose reel.

These are some of the possible options:

  • Demountable unit (with twist-locks)
  • Rear cabinet in fiberglass or lateral in aluminium
  • Vapor & liquid recovery piston compressor (or blade type for liquid only)
  • Vapor hose reel
  • ATEX approved emergency and/or control wireless system
  • Mass/vortex/turbine meters with electronic register
  • Flow sight indicator on filling line
  • Hydraulic oil cooler (for hot countries / big discharge volumes)

Dry tank / digital content indicator (also with GPS functions)

  • Bobtails (1)

    LPG bobtail 10m3 vol. capacity – rear fiberglass cabinet – max width 1,81mts

  • Bobtails (2)

    LPG bobtail – Instruments panel details

  • Bobtails (3)

    ADR/TPED LPG bobtail on 4 axles rigid unit, vol. capacity 37m3

  • Bobtails (4)

    S.I.I. approved LPG bobtail on 6×4 rigid unit, vol. capacity 28m3

  • Bobtails (5)

    ASME approved LPG bobtail on 6×4 rigid unit, vol. capacity 23m4

  • Bobtails (6)

    Printer and lap pad for electronic register detail

  • Bobtails (7)

    ADR/TPED/UAE Civil Defense approved LPG bobtail on GVW12 tons rigid unit, vol. capacity 10,8m3

  • Bobtails (8)

    LPG bobtail (26m3)+ self-carrying trailer (34m3) – ADR/TPED – According Norwegian road regulations

  • Bobtails (9)

    ADR/TPED/UAE Civil Defense approved LPG bobtail on GVW 18tons rigid unit, vol. capacity 18,4m3

  • Bobtails (10)

    Drybreak lateral APC connectors detail

  • Bobtails (11)

    ADR/TPED LPG bobtail on GVW 18tons rigid unit, vol. capacity 18,4m3 – Repsol specifications

  • Bobtails (12)

    Transfer plant detail

  • Bobtails (13)

    LPG bobtail – 4 ways valve on compressor detail

  • Bobtails (14)

    ASME LPG bobtail on 6×4 rigid unit, vol. capacity 30m3 – Petrogas specifications

  • Bobtails (15)

    ASME LPG bobtail on 6×4 rigid unit, vol. capacity 26m3 – Adnoc/Emirates Gas specifications.

  • Bobtails (16)

    ADR/TPED LPG bobtail on 6×4 rigid unit, vol. capacity 28m3 – Adnoc/Emirates Gas specifications

  • Bobtails (17)

    LPG bobtail 16m3 vol. capacity – rear cabinet

  • Bobtails (18)

    LPG bobtail 16m3 – ADR/TPED – Tunisian approval

  • Bobtails (19)

    LPG bobtails 28m3 – Codap – Algerian approval

  • Bobtails (20)

    ADR/TPED LPG bobtail on 4×2 rigid unit with compressor , vol. capacity 18m3 – Adnoc/Emirates Gas specifications

  • Bobtails (21)

    LPG bobtail 5m3 vol. capacity – rear cabinet – max width 1,75mts

  • Bobtails (22)

    Transfer plant detail

  • Bobtails (23)

    LPG bobtail tank 19m3 with intumescent coating for jet fire / pool fire

  • Bobtails (24)

    LPG bobtail 3,6m3 vol. capacity – rear cabinet – max width 1,8mts

  • Bobtails (25)

    LPG bobtail 16m3 vol. capacity – rear cabinet – compressor

  • Bobtails (26)

    LPG bobtail 5m3 vol. capacity – rear cabinet – max width 1,75mts

  • Bobtails (27)

    Transfer plant detail

  • Bobtails (28)

    LPG bobtails 27m3 – ADR/TPED – Tunisian approval
